Product Features:

• Higher power generation - better LCOE.
• N-type with very low LID.
• Better weak illumination response.
• Better temperature coefficient.
• Comes with a 15-year product warrant and 30-year linear power output warranty.

Due to size of the panels and size of the gap between the slats of the pallets (both length and width entries) a fork lift truck on site is required to offload these modules.

This product must be installed by a qualified electrician/technician. All installations must adhere to local wiring regulations and standards. Powerland will not be held liable for any product malfunctions as a result of incorrectly installed systems.

Supplier Part No:

JAM60D-42-540-LB-TS-BF

Weight:

28.8 kg

Rated Power:

540 W

MCS Reference:

BABT17001-1016-540W

Length:

2,063 mm

Width:

1,134 mm

Depth:

30 mm

VMPP:

37.25 V

IMPP:

14.5 A

Isc:

15.36 A

Voc:

44.33 V

Temp. Coefficient (Mpp):

-0.3 %

Clamp position on panel:

Long side only

Connector Description:

EVO2

Connector Type:

EVO2

Efficiency:

23.1 %

Pallet Size:

Oversized
